Activated Carbon for Flue and gas treatment

Urban and industrial growth of many countries across the world has made purified air, a primary and

  • Introduction

Urban and industrial growth of many countries across the world has made purified air, a primary and growing need. To battle the rising levels of contaminants in the air we breathe Haycarb Activated Carbon Air series offers a range of standard, impregnated, and specialized activated carbon products for a wide spectrum of air purification applications.

The dynamic product array of the Haycarb Activated Carbon Air series is developed to meet stringent emission control regulations as well as safety standards for emerging respirator technologies effectively removing nuisance odors, volatile organics, and hazardous chemicals from air and gas streams. We further offer carbons with superior butane and toluene capacity to OEM manufacturers of cabin air filters, air filters for libraries, museums and archives,  control room corrosive contaminant removal, equipment filters and pressure swing adsorption. Our products are tailor made to have a highly microporous structure to trap even the smallest VOC while the particle size distribution is maintained at optimum levels consistently to allow desired pressure drop under minimum air flow resistance.

For industrial operations we offer a range of carbon solutions for CO2 purification requirements, recovery of solvents, and to battle environmental challenges due to emission of flue gases, other industrial waste gases, sewage air as well as the highly dangerous emission of mercury vapor, particularly from coal power plants. Given our wide portfolio of products for air purification, whatever your requirement is, Haycarb Activated Carbon Air Series offers total solutions customizable to support your exact requirement, systems and operational conditions.

Over the years, nuisance odors produced in sewage treatment plants caused mainly by hydrogen sulfide and organic sulfur components have become a major concern. These gases, due to high toxicity, corrosiveness, and other adverse effects on health and environment are essential to be removed from air prior to releasing to the environment. Haycarb range of activated carbons for sewage air treatment have been designed to remove these highly malodorous and pungent odors released in pumping stations, primary clarifies and filter press rooms of sewage treatment plants.

Our carbon is manufactured using a proprietary process that ensures the best hydrogen sulfide removal capacity at different process conditions while eliminating the risk of bed fire caused by heat released during chemisorption. Unlike competitor products, Haycarb carbon will not disintegrate in wet conditions and therefore is a better suited choice for sewage treatment applications. The use of coconut shell carbon further increase capacity to also adsorb organic compounds. This product is therefore an economical and safe solution to eliminate these nuisance odors and can be customized to ensure a best fit solution for you.

Datasheet:

Material


Size

mesh

Iodine Value
≥ mg/g

Methylene Blue
≥ mg/0.1g

Strength
≥ %

Ash Cont
≤ %

Water Cont

≤ %

Density

g/L

Ph Value



Coconut Shell

4×8

900

150

97

5

10

0.45-0.55

6-11

Coconut Shell

6×12

1000

180

97

5

10

0.45-0.55

6-11

Coconut Shell

8×16

1100

190

97

5

10

0.45-0.55

6-11

Coconut Shell

10×20

1200

195

97

5

10

0.45-0.55

6-11

Coconut Shell

12×40

1300

200

97

5

10

0.45-0.55

6-11

Coconut Shell

8×30

1400

205

97

5

10

0.45-0.55

6-11

Coconut Shell

20×40

1300

210

97

5

10

0.45-0.55

6-11

Coconut Shell

30×60

1300

220

97

5

10

0.45-0.55

6-11

Remarks:

  1. Special requirements can be customerized according to customer's requirements.

  2. Production capacity: 500 tons/month

  3. Standard according to Chinese XXXXX and ASIM ,JIS
